Architectural · A-JNPFY

Stair Section - Atrium - Landing

Scale: 1/4" = 1'-0"
Units: imperial
Sheet: A5.11
Discipline: Architectural

Elements

Floors / Slabs Stairs

Text on the drawing

3RD FL. 454' - 7 3/4" 4TH FL. 468' - 7 3/4" A5.12 1 F4 F4 460C 460B
