An SBS modified bituminous roofing membrane applies over the roof deck with a slope of 1/2 inch per foot. An overflow drain is installed with an insert standpipe extending 2 inches above the finished roof level.
SLOPE 1/2" PER FT. OVERFLOW DRAIN WITH INSERT STANDPIPE 2" ABOVE FIN. ROOF SBS MODIFIED BITUMINOUS ROOFING
