Text on the drawing
SEE DOOR SCHEDULE 1'-0" 1'-1" 2 1/2" 3/4" 1 3/4" 3/4" 2 1/2" D4 A-554 D3 A-554 2'-0" 2'-0" 3/16" TYP. TOP ESCUTCHEON SECURED IN PLACE WITH SET SCREW EYE HOOK LOCATION TYP. EACH STATION LANGUAGE CARD CLIP LOCATION EYE HOOK LOCATION TYP. EACH STATION
