An extruded aluminum frame receives scheduled glass secured with glazing gaskets at the head of the partition. The aluminum framing section coordinates with the partition type and abuts the metal runner track and metal studs of the framing above. Gypsum board finishes both sides of the wall assembly over a sound attenuation blanket. A scheduled ceiling aligns with the head detail as indicated on the reflected ceiling plan.
AS SCHEDULED GYPSUM BOARD METAL STUD METAL RUNNER TRACK SCHEDULED CEILING, SEE RCP EXTRUDED ALUM FRAME 1 1/2" 3/8" PARTITION TYPE COORDINATE WITH GLAZING GASKET GLASS AS SCHEDULED SOUND ATTENUATION BLANKET
