An stainless steel gravel stop with a drip and hemmed edge terminates the edge of a TPO roofing membrane and protection board laid over roof framing. The TPO membrane wraps over the eave and is secured with lap sealant. Below the roof assembly, metal stud soffit framing is finished with a stainless steel J-trim and metal panel MP-3.
1/2" 3/4" 1 3/4" 11 3/8" SST gravel stop with drip and hemmed edge TPO roofing Protection board Metal stud soffit framing, see structural MP-3 SST j-trim Lap sealant Weld TPO and wrap over eave
