This millwork detail shows a reception desk drawer box framed with an MDF substrate and finished with DMP-4 material. All exposed edges of the cabinet are specified to receive the DMP-4 finish. Dimensional callouts indicate specific clearances and thicknesses for the drawer face and enclosure.
1 " 1 / 4 " 4 3 / 4 " 1 / 8 " D M P - 4 M D F S U B S T R A T E D R A W E R B O X *ALL EXPOSED EDGES OF CABINET TO BE DMP-4
