A two-inch steel pipe rests on a three-eighths-inch saddle plate welded with five-sixteenths-inch typical fillet welds. The saddle plate is supported by a ten-inch vertical assembly featuring a one-half-inch stiffener plate. The entire support structure is mounted atop an HSS 10x10 hollow structural section column, secured with five-sixteenths-inch typical fillet welds.
(TYP) 2" STEEL PIPE PER MECHANICAL DRAWINGS HSS 10x10 SADDLE PL 3/8 5/16 (TYP) STIFFENER PL 1/2 SECTION C 5/16 5/16 10" (TYP)
