A hollow structural section girt is supported by an L4x4x1/4 angle measuring five inches long, welded with three-sixteenths inch fillet welds typical. A 1/4 inch by 4 inch by 9 1/2 inch plate is centered on the hollow structural section column per plan. A cap plate is provided per detail 3/3.S-510, and a standard slotted hole accommodates a 3/4 inch diameter A325 bolt. The assembly ties the girt into the column framing with specified plate sizes and weld sizing.
RAE 02 120' - 4 13/16" X COL PER PLAN GIRT PER PLAN L4X4X1/4 X 5" 3/16 3/16 TYP PL 1/4 X 4 X 9 1/2", CENTER ON HSS CAP PL PER 3/3.S-510 SSL FOR 3/4"ø A325 BOLT 1' - 3" 2" 2 1/2"
