This wall cabinet assembly mounts against a finished wall line and features adjustable interior shelving with door panels and pulls. A fascia panel is included at the top where applicable, along with under-cabinet lighting. Openings for electrical boxes must be coordinated through the finish wall line. An optional ceramic tile finish is specified at the wall where indicated.
1' - 2" 3" 2' - 1" UNO FINISH WALL LINE COORDINATE OPENINGS FOR ELECTRICAL BOXES UNDER-CABINET LIGHTING ADJUSTABLE SHELVING DOOR PANEL FASCIA PANEL, WHERE OCCUR DOOR PULL TILE FINISH (CT) WHERE OCCUR B3 WALL CABINET
