A swinging gate assembly utilizes a 4x4x3/16 inch hollow structural section gate frame paired with a 2x2x3/16 inch ledger frame. The frame is finished with a primed and painted coating and integrates with a 1-1/2 inch primed and painted metal deck. A 3/4 inch diameter drop bar secures into a 3/4 inch standard by 3 inch long guide assembly. All structural steel components are specified for exterior metal gate applications.
1 1/2" METAL DECK, PRIMED AND PAINTED 3/4" Ø DROP BAR 3/4" Ø STD X 3" LONG HSS 4 X 4 X 3/16" GATE FRAME 2 X 2 X 3/16 LEDGER FRAME PRIMED AND PAINTED STEEL GATE FRAME 1/2" = 1'-0" A012 2 SWINGING GATE SECTION
