The assembly consists of an eighteen by twenty-four inch acrylic sign featuring screen-printed text and artwork laminated between two panels. Each sign contains a different graphic with locations determined and field verified. The unit is wall mounted using expansion bolts at each of the four corners. All corners feature a one-half inch radius.
1' - 6" 2' - 0" 18 "x 24" ACRYLIC SIGN WITH SCREEN PRINTED TEXT AND ARTWORK (GRAPHICS TO BE DIGITALLY PROVIDED BY ARCHITECT). LAMINATED BETWEEN TWO PANELS AND WALL MOUNTED. EACH SIGN TO BE A DIFFERENT GRAPHIC. LOCATIONS TO BE DETERMINED AND FIELD VERIFIED. MOUNT TO WALL WITH EXPANSION BOLTS AT EACH CORNER. CORNERS TO HAVE A 1/2" RADIUS. B5 A660 STROMBERG STUDENT ACTIVITY CENTER SCALE: 3" = 1'-0" C4 SIGN TYPE B
