Surface mounted and flush mounted stainless steel corner guards attach to wall framing with number six by one and five-eighths inch bugle head sheet metal screws at eighteen inches on center maximum. A sponge neoprene backing is field installed behind the end wall cap. Wall protection panels featuring Aspex panels with graphics align with the ceiling height.
06 64 00 WALL PROTECTION PANEL ASPEX PANEL WITH GRAPHIC CEILING HEIGHT ALIGN 10 26 00 END WALL CAP 10 26 00 #6 x 1 5/8" BUGLE HD SMS @ 18" OC MAX WALL FRAMING SPONGE NEOPRENE (FIELD INSTALLED) 2" CLR WHERE OCCURS SURFACE MOUNTED FLUSH MOUNTED 3" = 1'-0" 28 SST CORNER GUARD 3" = 1'-0" 29 END WALL CAP
