An insulated overhead coiling door housing mounts adjacent to an eight-inch concrete masonry unit wall with a concrete core. The wall features an exterior elastomeric coating. Continuous aluminum flashing at the door head incorporates weep holes spaced at a maximum of twenty-four inches on center. An eight-inch concrete masonry unit lintel spans the masonry opening, with the door housing aligned to the masonry opening dimension point.
Text on the drawing
CMU WALL ASSEMBLY E01 INSULATED OVERHEAD COILING DOOR M.O. DIM PT. 8" CMU LINTEL ROLL UP DOOR HOUSING, PAINTED. EXTERIOR ELASTOMERIC COATING 8" CMU, CONCRETE CORE CONTINUOUS ALUMINUM FLASHING AND PROVIDE WEEP HOLE AT 24" O.C MAX INSULATED OVERHEAD COILING
