This wall-mounted bar top assembly features a finished top surface supported by 2x steel tube framing with chamfered ends and smooth edges, painted with finish P-7A, and capped at the exposed end with a color-matched cover. The structural framework utilizes nested HSS 3x3x1/4 hollow structural sections welded or attached to a 3-inch by 8-1/2 inch by 3/8-inch plate, secured with two expansion bolt anchors having a 3-inch embedment into the backing wall. The supporting wall assembly consists of a 3-5/8 inch metal stud framing with 5/8-inch moisture resistant gypsum board and white FRP on the service side, and 5/8-inch gypsum board with finish tile on the opposite side. The flooring below is finished with tile and base as scheduled, providing a 3-foot 2-5/8 inch clear height beneath a 3-foot 6-inch total equipment clearance zone.
FINISHED TOP - SEE CW SHEETS 2X STEEL TUBE - CHAMFER END AND SMOOTH EDGES PAINT P-7A 3' - 6" EQUIPMENT - SEE FOOD SERVICE WALL ASSEMBLY: WHITE FRP - SERVICE SIDE 5/8" MOISTURE RESISTANT GYP. BD. 3-5/8" METAL STUD 5/8" GYPSUM BOARD TILE - SEE FINISH PLANS NESTED HSS 3x3x1/4 WITH 3" x 8 1/2" x3/8" PLATE WITH (2) EXPANSION BOLT ANCHORS - 3" EMBED SEE PLAN FOR LOCATION TILE FLOOR AND BASE AS SCHEDULED 2' - 0" 1 1/4" 6" 1 1/4" 3" 1 1/2" 1 1/2" 4 1/4" 4 1/4" 8 1/2" PLAN VIEW 3' - 2" CLEAR 3' - 2 5/8" PROVIDE CAP AT EXPOSED END. COLOR TO MATCH STEEL 2" 3"
