An acoustic ceiling tile panel interfaces with a gypsum board ceiling system finished with corner bead. The assembly is supported by six-inch eighteen-gauge metal studs spaced at sixteen inches on center. A four-inch metal stud brace is installed at a maximum forty-five degree angle spaced at four feet on center. Typical acoustic ceiling tile trim finishes the perimeter edge at the transition line.
SEE RCP SEE RCP GYP BD W/ CORNER BEAD ACT PANEL 6" MTL STUD 18 GA 4" @ 16" OC 4" STUD BRACE @ 4'-0" OC MAX 45.00° ACT TRIM, TYP.
