A-J4AZ7 — Rated Wall at Stair to Conc Wall

Architectural · A-J4AZ7

Rated Wall at Stair to Conc Wall

Scale: SCALE: 1 1/2" = 1'-0"
Units: imperial
Sheet: A5
Discipline: Architectural

Materials

Composite Concrete

Elements

Bracing Decks Floors / Slabs Foundations / Footings Partitions Railings / Guards Stairs Walls

Connections

Bracing Connection Shear Stud / Composite

Text on the drawing

LEVEL 1 100'-0" 7 CONC. FOUNDATION WALL - RE: STRUCTURAL HANDRAIL (BEYOND) STAIR (BEYOND) 6 7/8" COMPOSITE CONCRETE DECK INTERIOR WALL ASSEMBLY RE: FLOOR PLANS FIRE-RATED ASSEMBLY RE: FLOOR PLAN BRACE BACK TO FOUNDATION WALL

Members view this detail in full resolution, download the CAD files (SVG, PDF), and open any detail in the built-in CAD editor to edit and export DXF or DWG.
