A wood barn door hangs from a trolley system positioned at eight feet six inches above finished floor to the top of the door. The double track mount spacer attaches to a one inch by two inch barn door rail, which is secured through a one inch by four inch stainless steel plate. A four inch by six inch by one-eighth inch steel tab mechanically fastens to the wall stud behind the gypsum board with flush-mounted bolts, requiring additional blocking as necessary. The assembly aligns with the centerline of the barn door system and the centerline of the tube.
2 5/8" 1 3/4" 8'-6" AFF TOP OF DOOR 2" 4" BARN DOOR TROLLEY SYSTEM LINE OF WALL BEYOND WOOD BARN DOOR 1" X 2" BARN DOOR RAIL 1" X 4" STAINLESS STEEL PLATE DOUBLE TRACK MOUNT SPACER CENTERLINE OF BARN DOOR SYSTEM CENTERLINE OF TUBE 4" X 6" X 1/8" STEEL TAB MECHANICALLY FASTENED TO STUD (BEHIND GYP BOARD. PROVIDE BLOCKING AS REQUIRED. FLUSH MOUNTED BOLT 3" = 1'-0" A-645 13 08_DOOR HEAD OPERABLE PARTITION @ TRACK
