A unitized aluminum curtain wall system incorporates pre-finished aluminum framing members and 1-3/16-inch thick insulating glass units designated as GL-1. The assembly features extruded aluminum mullion profiles designed for balcony conditions with specialized glazing pockets and gaskets. The exterior and interior finish components are coordinated with material designation E-MTL-01 and wall assembly code E-WA-04A.
08 4400 UNITIZED ALUMINUM CURTAIN WALL, E-WA-04A 08 4400 PRE-FINISHED ALUMINUM, E-MTL-01 08 4400 1-3/16" [30 MM] INSULATING GLASS UNITS, GL-1 08 4400 PRE-FINISHED ALUMINUM, E-MTL-01 UNITIZED ALUMINUM CURTAIN PRE-FINISHED ALUMINUM, 1-3/16" [30 MM] INSULATING 1-3/16" [30 MM] INSULATING PRE-FINISHED ALUMINUM,
