An extruded aluminum electro pocket houses a motorized roller tube and shade band with a regular roll assembly. The system is secured using a standard mounting bracket attached to the wall framing. A removable closure provides access to the 6 and 1/2 inch wide pocket assembly. The hem bar is sealed inside the shade cloth when the blackout shade is in the up position.
#4155 ELECTRO POCKET CL 6 1/2" REMOVABLE CLOSURE BLACKOUT SHADE IN DOWN POSITION VARIES CEILING, REF. REFLECTED CEILING PLAN ELECTRO 1 STANDARD BRACKET ROLLER TUBE AND SHADE BAND REGULAR ROLL ASSEMBLY (MOTOR INSIDE TUBE) HEM BAR SEALED INSIDE SHADECLOTH IN UP POSITION
