Casework pull hardware is mounted typically one and one-half inches from the edge as shown on the elevation, with identification type per the specification manual. The pulls are positioned two inches from the cabinet base according to standard installation requirements.
1 1/2" TYP 2" PULL HARDWARE, CASEWORK PULLS TO BE MOUNTED AS SHOWN ON ELEVATION, SEE SPECIFICATION MANUAL FOR IDENTIFICATION TYPE
