An exterior wall section shows the transition joint between an aluminum composite material panel and an exterior plaster finish. The ACM panel assembly ties back to substrate framing with continuous water-resistive barriers and sub-framing components. A three-quarter-inch joint separates the upper ACM panel cladding from the lower exterior plaster system. Flashing and joint sealants manage moisture migration at the horizontal intersection point.
ACM PANEL EXTERIOR PLASTER PER ELEV. W.P. EQ EQ WD79 WD89 WD92 WD85 WD77 WD101 WD97 WD95 WD98 3/4"
