Insulated precast concrete sandwich panels meet at a mitered corner with a one-inch joint gap. Steel embed plates and a structural steel angle secure the panel connection. The joint is sealed with backer rods and sealant, featuring one on the interior side and two on the exterior side. Fire-rated sealant is provided to match the wall rating referenced in the life safety plans.
INSULATED PRECAST CONCRETE PANEL BACKER ROD AND SEALANT. ONE ON INTERIOR SIDE, TWO ON EXTERIOR SIDE; PROVIDE FIRE RATED SEALANT TO MATCH WALL RATING, REF. LIFE SAFETY PLANS 1" 1" JOINT; VERT. OR HOR. WALL SANDWICH PANEL INSULATED PRECAST CONCRETE PANEL STEEL EMBED PLATES PER STRUCTURAL STEEL ANGLE PER STRUCTURAL INTERIOR EXTERIOR BACKER ROD AND SEALANT. ONE ON INTERIOR SIDE, TWO ON EXTERIOR SIDE; PROVIDE FIRE RATED SEALANT TO MATCH WALL RATING, REF. LIFE SAFETY PLANS
