Architectural · A-HX95F

Diffuser Panel Detail

Scale: SCALE: 6" = 1'-0"
Units: imperial
Sheet: A5
Discipline: Architectural

Materials

Metal (misc.)Timber / Wood

Elements

Millwork / Casework Walls

Text on the drawing

DECORATIVE METAL GRILL. SEE DETAIL A1/A-626 FOR ELEVATION WOOD GRILL FRAME, T80 MAGNET WAINSCOT PLYWOOD
