A-HWZEQ — Foundation Detail - Top of Wall at Modular Rainscreen

Architectural · A-HWZEQ

Foundation Detail - Top of Wall at Modular Rainscreen

Scale: 1 1/2" = 1'-0"
Units: imperial
Sheet: A7.01
Discipline: Architectural

Materials

Aluminum Composite Concrete Membrane / Roofing Reinforced Concrete

Elements

Drainage Facades / Cladding Floors / Slabs Foundations / Footings Insulation Site / Paving Stem Walls Walls Waterproofing / Flashing

Text on the drawing

1ST FL. 424.65' F CONCRETE SLAB PER STRUCTURAL WRB. LAP OVER TWF TWF WATERSTOP BENTONITE PANEL DRAIN BOARD SITE PAVING WP TERMINATION PER MFR DETAIL INSULATION PKG-2 EW5 EW5 ALU SUB-FRAME SYSTEM VENT CLOSURE ALU SUB-FRAME RAIN SCREEN PANEL SEALANT 4" 1"
