A-HVW4Z — 19Mm Dia Stainless Steel "U" Bar

Architectural · A-HVW4Z

19Mm Dia Stainless Steel "U" Bar

Units: imperial
Sheet: A-MB-8.10
Discipline: Architectural

Materials

Membrane / Roofing Metal (misc.)Stainless Steel Steel

Elements

Connections / Plates Roofs Waterproofing / Flashing

Connections

HSS Connection Welded Connection

Text on the drawing

REFER TO STRUCT. DWGS FOR CONNECTION 200 MIN. WATER TIGHT CAP GALVANIZED H.S.S. TUBING 19mm DIA STAINLESS STEEL "U" BAR WELD TO CAP PLATE GALVANIZED H.S.S. TUBING FLASHING FLANGE (MIN. 100mm) SET IN COMPATIBLE SEALANT ROOF MEMBRANE UP (TYP.) STAINLESS STEEL CLAMPING RING RF1

Members view this detail in full resolution, download the CAD files (SVG, PDF), and open any detail in the built-in CAD editor to edit and export DXF or DWG.
