Aluminum storefront base mullion with vision glass insulated glass units intersects with a concrete curb. A painted aluminum close mesh bar grating covers a recessed gutter supported by tapered insulation over a composite metal deck. The exterior wall features solid surface cladding with angled glued corners, supported by wall brackets, studs, and an L-profile over insulation and a weather barrier membrane with a 1-inch ventilation gap.
ALUMINUM BASE MULLION STORE FRONT VISION GLASS IGU CLOSE MESH BAR GRATING, ALUMINUM, PAINTED SOLID SURFACE CLADDING WITH ANGLED (GLUED) CORNER TAPERED INSULATION WITH GUTTER WATER PROOFING MEMBRANE COMPOSITE METAL DECK CONCRETE CURB 1 1/4" 1'-0" 9" 4'-0" 1" 1'-0" SOLID SURFACE CLADDING -ANGLED (GLUED)CORNER WITH OVERLAP 6" 4'-0" CLAMP WALL-BRACKET VENTILATION GAP INSULATION L-PROFILE STUD TYVEK COMMERCIAL WRAP OR TYVEC FLUID APPLIED WB ALLOW 1" OPEN JOINTS AT BOTTOM AND TOP FOR VENTILATION
