A-HVBWG — Stair Landing Detail

Architectural · A-HVBWG

Stair Landing Detail

Scale: SCALE: 1 1/2" = 1'-0"
Units: imperial
Sheet: A-563
Discipline: Architectural

Materials

Cold-formed Steel Concrete Gypsum / Drywall Metal (misc.)Timber / Wood

Elements

Partitions Stairs

Text on the drawing

H.6 J C4 A-401 CORNICE. SEE TRIM SCHEDULE ON SHEET A-622, T42 5/8" GYPSUM BOARD 3 5/8" METAL STUD CONCRETE FILLED METAL PAN STAIR CARPETING ON STAIR SEE FINISH PLANS 1" GYPSUM BOARD RUNNER TRACK 6" METAL STUD
