Two sections of twenty-four gauge clad edge metal are joined with a one-quarter inch gap, secured by galvanized ring shank screws at six inches on center in two staggered rows. A two-inch wide aluminum tape is applied over the joint, followed by thermoplastic flashing welded over the joint and extending four inches down the face.
14 " GAP 24 GA. CLAD EDGE METAL GALVANIZED RING SHANK SCREWS, 6" O.C., TWO ROWS, STAGGERED THERMOPLASTIC FLASHING WELDED OVER JOINT AND DOWN FACE 4" 3" TYP. 2" 2" WIDE ALUMINUM TAPE OVER JOINT
