An aluminum curtain wall vertical mullion aligns with the Level 02 floor line at one hundred eighteen feet elevation. Curtain wall glass is retained within the framing system. A four-inch aluminum curtain wall vertical mullion extends beyond the connection point.
118' - 0" LEVEL 02 CW GLASS ALUM CW MULLION - LOBBY 4" ALUM CW VERTICAL MULLION BEYOND
