An adhesive-mounted mirror is attached to a plywood substrate, which is hung on the wall using one-quarter inch metal cleats between tile finishes. A stainless steel countertop featuring an integral stainless steel sink rests on a concealed counter support painted black, with exposed surfaces of the plywood substrate also painted black. The dashed lines indicate the required accessible space clearance below the counter. Faucet and soap dispenser locations are coordinated per schedule.
SSTN COUNTERTOP INTEGRAL SSTN SINK FACE OF FINISHED PARTITION DASHED LINE OF ACCESSIBLE SPACE CONCEALED COUNTER SUPPORT PAINTED BLACK. VERIFY LOCATIONS WITH ARCHITECT. 2 " 5 " 1 1 / 4 " 2 ' - 0 " 4 " PAINT EXPOSED SURFACES OF PLYWD SUBSTRATE BLACK FAUCET / SOAP DISPENCER SCHEDULE 6 " 5 " 8 " 9 " 3 / 4 " 1 " 3 / 4 " 1 " M I R R O R , A D H E S I V E M O U N T E D T O P L Y W O O D S U B S T R A T E P L Y W O O D S U B S T R A T E M O U N T E D T O W A L L W / 1 / 4 " M E T A L C L E A T S COUNTERTOP OR FLOOR PER ELEVATION TILE PER ELEVATION TILE PER ELEVATION
