An aluminum and glass storefront system forms a complex pleat corner using nine-sixteenth-inch monolithic laminated glass designated GL-3 with reinforcing provided as required. The aluminum framing members incorporate a custom light interference coating labeled E-MTL-05 at the corner junction.
9/16" [13 MM] MONOLITHIC, LAMINATED GLASS, REINFORCING AS REQUIRED REINFORCING AS REQUIRED 08 4400 ALUMINUM AND GLASS STOREFRONT SYSTEM, E-WA-01A 08 4400 9/16" [13 MM] MONOLITHIC, LAMINATED GLASS, GL-3 08 4400 CUSTOM LIGHT INTERFERENCE COATING, E-MTL-05
