Architectural · A-HNSV2

Plan Detail Room 105

Scale: SCALE: 1" = 1'-0"
Units: imperial
Sheet: A5
Discipline: Architectural

Elements

Floors / Slabs Partitions Walls

Text on the drawing

5 ACOUSTIC WALL ASSEMBLY RE: FLOOR PLANS PLUMBING WALL TILE (WHERE OCCURS) A6G A6G

Members view this detail in full resolution, download the CAD files (SVG, PDF), and open any detail in the built-in CAD editor to edit and export DXF or DWG.
