This suspended ceiling assembly consists of a five-eighths-inch gypsum board ceiling hung from the underside of the structure above using number eight hanger wires typical. Seven-eighths-inch hat track furring runs perpendicular to one-and-a-half-inch channels spaced at four feet on center. Where the ceiling width exceeds eight feet, one-and-a-half-inch cold-rolled steel C-channels are provided perpendicular to the runners. Water-resistant gypsum board is specified for use in restrooms and wet areas. This detail is specifically designated for conditions where the span of the ceiling system exceeds twenty-five feet in both directions.
NOTE: THIS DETAIL SHALL BE USED IN CONDITIONS WHERE THE SPAN OF THE CEILING SYSTEM EXCEEDS 25 FEET IN BOTH DIRECTIONS. 2" MIN. 3/4" 2" 2" SUSPENDED 5/8" GYP. BOARD CEILING USE WATER RESISTANT GYP. BD. IN RESTROOMS OR WET AREAS. 1 1/2" CHANNELS AT 4'-0" O.C. WHERE CEILING IS GREATER THAN 8'-0" IN WIDTH, PROVIDE 1 1/2" COLD ROLLED STEEL "C" CHANNELS PERPENDICULAR TO RUNNERS. 7/8" HAT TRACK FURRING. #8 HANGER WIRE TYP. TO UNDERSIDE OF STRUCTURE ABOVE. SEE REF. CEILING PLAN FOR CEILING HEIGHTS
