A glass panel guard rail connects to a painted hollow structural section stair stringer using stand-off bases with two-inch diameter caps. A handrail projects one foot from the glass panel assembly. The stair landing structure integrates with the stringer and stand-offs. Dimensions indicate a six-inch vertical spacing and a three-inch spacing at the base. A plan view shows the relative positioning of the glass panel, handrail, and structural supports.
HSS STRINGER, PAINTED, RE: STRUCTURAL 1" 6" 3" STAND-OFF BASE & 2" DIA CAP PLAN VIEW B3 A521 Sim GLASS PANEL HANDRAIL 1'-0" SCALE: 3" = 1'-0" B4 TYP GUARD RAIL DETAIL
