A roof drain assembly connects to the roof structure with a drain clamping ring securing the roofing system flashing membrane. Butyl sealant is applied beneath the flange, and bonding adhesive secures the flashing membrane over the roofing system membrane. Rigid insulation with a minimum thickness of six inches slopes toward the drain. Fasteners including number fourteen by two-inch heavy-duty fasteners and Piranha plates are spaced at twelve inches on center.
BUTYL SEALANT ROOFING SYSTEM FLASHING MEMBRANE BONDING ADHESIVE ROOFING SYSTEM MEMBRANE #14x2" HD 14-10 FASTENERS AND "PIRANHA" PLATE @ 12" O.C. ROOF ASSEMBLY PER DETAIL DRAIN CLAMP RING DRAIN HEAT WELDED LAP 6" MIN. RIGID INSULATION, SLOPE TO DRAIN
Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
