This elevation shows a four-sided bracket constructed from three by six inch aluminum tubes designed by build, featuring multiple voids within the bracket assembly. Dimensions vary in field across the five foot six and three-quarter inch width and nine foot three inch height, with specific angular and linear spacings indicated throughout. A central vertical member aligns with the centerline and ties into a steel base bracket at the bottom. Various typical dimensions and alignment notes are provided for fabrication and field verification.
D - FRONT B 5'-6 3/4" VIF C L 5'-6 3/4"VIF 9'-3" VIF 1'-9 3/4" VIF 44° 6" TYP 1'-10 5/8" VIF FOUR SIDED BRACKET, 3"X6" ALUM. TUBE BY DESIGN BUILD, TYP. 66.5° VIF 3" TYP 1 1/2" TYP ALIGN C L "VOID" REPRESENTS: VOID IN BRACKET VOID VOID VOID VOID VOID VOID STEEL BASE BRACKET 1C - 3 -
