A-HF6RJ — East Terrace Guardrail at Transition

Architectural · A-HF6RJ

East Terrace Guardrail at Transition

Scale: 3" = 1'-0"
Units: imperial
Sheet: A7.42
Discipline: Architectural

Materials

Brick EIFS / Plaster / Stucco Metal (misc.)Timber / Wood

Elements

Expansion / Control Joints Facades / Cladding Railings / Guards Waterproofing / Flashing

Connections

Bolted Connection Welded Connection

Text on the drawing

1/4" SEALANT JOINT WRB BRICK RETURN METAL FLASHING RAILING ATTACHMENT TAB FULL HEIGHT GUARD RAIL CABLE RAIL GUARD RAIL INSIDE CORNER TRIM BLOCKING AS REQUIRED FOR RAILING ATTACHMENT FIBER CEMENT BOARD WRB RAILING PANEL ABOVE 2 1/2" 1" 6" 3/8"
