Architectural · A-HDWDG

Concrete Masonry Unit Partition Type

Materials

Concrete Masonry / CMU

Elements

Partitions

About this detail

Concrete masonry units are specified with classification D-2 for a two-hour fire rating and classification C-3 for a three-hour fire rating.

04 20 00.A00 CONC MASONRY UNIT CLASSIFICATION D-2 FOR 2-HR C-3 FOR 3-HR

Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
