This television soffit section details a wall assembly supported by either three-and-five-eighths-inch or six-inch metal studs spaced at sixteen inches on center. The wall face is clad with five-eighths-inch fire-retardant plywood to provide backing for the television mount. The overall vertical dimension of the section is three feet four inches, with the ceiling condition coordinated per the reflected ceiling plan and wall types sized per plan.
REFER TO DETAIL 4 FOR SIMILAR NOTES AND DIMENSIONS WALL SUPPORT: 3 5/8" MTL STUD @ 16" OC 6" MTL STUD @ 16" OC 5/8" FRT PLYWOOD 3' - 4" SEE RCP SEE PLAN FOR WALL TYPE
