An angled compression strut lateral bracing member connects to the main runner track using two one-half-inch diameter machine bolts, sized per schedule according to the kicker length. A twelve-gauge steel clip matching the stud width secures the lower end of the kicker to the partition framing with two number-ten self-tapping sheet metal screws at each end. A sizing schedule defines the required cold-formed steel stud profiles for lengths up to fourteen feet.
2" MAX KICKER LENGTH KICKER SIZE < = 4'-0" 250S137-43 < = 8'-0" 400S162-43 < = 14'-0" 400S162-54 12 GA STEEL CLIP, MATCH STUD WIDTH, LENGTH AS REQ, ATTACH W/ (2) #10 SELF TAP SM SCREWS EA END KICKER PER SCHED; REFER TO KICKER DETAILS FOR ATTACHMENT METHODS TO SIDE OF PARTITION TO STRUCTURE ABOVE ANGLED KICKER LAT. BRACING COMPRESSION STRUT PER SCHEDULE - ATTACH TO MAIN RUNNER TRACK W/ (2) 1/2" DIA MACHINE BOLTS. REFER TO STRUT DETAILS FOR ATTACHMENT METHODS FOR TRAPEZE CONDITIONS ABOVE
