High and low side reach limits are established at forty-eight inches above finished floor and fifteen inches above finished floor respectively. These dimensions regulate the installation heights for operable parts and building controls to maintain accessibility compliance.
48" 15" HIGH AND LOW SIDE REACH LIMITS OF 48" AFF AND 15" AFF (ABOVE FINISHED FLOOR) FIGURE 2. SIDE REACH
