A vertical pipe penetrates a concrete structural slab topped with air vapor barrier, insulation sloped to drain at one-quarter inch per foot minimum, roof coverboard, and an SBS modified bituminous roofing system. Liquid-applied PMMA flashing extends up the pipe base and integrates with the roof membrane. A stainless steel umbrella flashing secures over the liquid flashing with a stainless steel draw band. A cap is welded watertight to the top of the pipe with sealant over a bond breaker sloped to drain.
ROOF COVERBOARD CONCRETE OVER DLT SLAB - S.S.D. TAPERED RIGID INSULATION SBS MODIFIED BITUMINOUS MEMBRANE ROOFING SYSTEM TORCH DOWN AIR VAPOR BARRIER 1/4" PER FOOT SLOPE MIN. WALK PAD WO, APPROX. 1/4" THICK SEALANT OVER BOND BREAKER, SLOPED TO DRAIN INSULATION SLOPED TO DRAIN AIR VAPOR BARRIER SEAL AROUND PIPE PMMA FLASHING SBS MODIFIED BITUMINOUS ROOFING CONCRETE OVER DLT SLAB, S.S.D. SS DRAW BAND SS UMBRELLA FLASHING CAP WELDED WATERTIGHT 3" MIN 8" MIN 6" MIN
