An exterior corner wall assembly features a hollow structural section post framed by six-inch, sixteen-gauge metal studs spaced at sixteen inches on center. The exterior finish consists of seven-eighths-inch cement plaster over metal lath and a weather-resistant barrier, protected by continuous wall flashing. A scupper downspout is positioned adjacent to the framed corner adjacent to an opening.
FEC 16 5X HSS SSD POST 7/8" CEMENT PLASTER OVER METAL LATH OVER WEATHER RESISTANT BARRIER 3 7/8" 5" WALL FLASHING OPENING 6" ,16 GA. @ 16" OC. METAL STUD SCUPPER DOWN SPROUT 1'-9 3/8" 5" 8 7/8" 2'-2 3/8"
