A 16-gauge by 6-inch continuous steel plate spans across metal stud framing to provide structural support for wall-mounted items. Three number 10 pan head sheet metal screws secure the plate to each stud. The framing consists of typical partitions featuring welded double studs at the sides of openings. Field verification of the length, height, location, and fastener requirements is necessary based on the specific mounted item.
A BACKING PLATE TYPE A (3) #10 PAN HEAD SMS PER STUD (TYP.) 16 GA. X 6" CONTINUOUS STEEL PLATE NOTES: 1. CONFIRM LENGTH, HEIGHT AND LOCATION OF BACKING PLATE AND NUMBER REQ'D WITH ITEM TO BE MOUNTED. TYPICAL PARTITIONS FRAMING; WELDED DOUBLE STUDS AT SIDES OF OPENINGS; SEE 18G/-
