Architectural · A-H5ZDJ

T221 - CUSTOM ROSETTE

Scale: SCALE: 6" = 1'-0"
Units: imperial
Sheet: A5
Discipline: Architectural

Materials

EIFS / Plaster / Stucco

Elements

Ceilings

Text on the drawing

R 7 5/8" CL CL DESIGN BASED ON FABER ORNAMENTAL PLASTERING CORP PART NUMBER CM-036 FOR MOUNTING SECTION DETAIL SEE A1/A-662
