An Inpro Formatrac Whisper Cube cubicle curtain track is secured directly to the underside of a suspended ceiling grid. The track is fastened using number 10 by one and one-quarter inch sheet metal screws spaced at twenty-four inches on center maximum. Ceiling tiles abut the track assembly adjacent to the grid flange.
CEILING TILES CEILING GRID #10 X 1 1/4" S.M.S. @ 24" O.C. MAX. CUBICLE CURTAIN, INPRO FORMATRAC CUBICLE CURTAIN TRACK, WHISPER CUBE
