A-H2MEV — Soffit Detail At Gyp Ceiling

Architectural · A-H2MEV

Soffit Detail At Gyp Ceiling

Scale: 3" = 1'-0"
Units: imperial
Sheet: A-900
Discipline: Architectural

Materials

Cold-formed Steel Gypsum / Drywall Metal (misc.)Timber / Wood

Elements

Text on the drawing

SEE RCP SEE RCP SEE RCP 5/8" GYPSUM BOARD, PTD CORNER BEAD 5/8" GYPSUM BOARD CEILING, PTD CLG JOIST, MTL STUD PER METAL TRACK CONTINUOUS WITH 2 #10 SMS AT EACH STUD. PROVIDE TOP AND BOTTOM SHEET MTL SCREW AT HORIZONTAL STUD TO TRACK FLANGE TYP / 2 A-900 VARIES
