A master remote control valve is housed inside a fourteen by nineteen inch valve box set flush with finish grade in turf areas and one inch above in shrub areas. The assembly connects to a PVC ring-tite mainline from the point of connection through a class two hundred PVC elbow and schedule eighty PVC components including unions, nipples of required length, reducer bushings, and a PVC ell. Four brick supports carry the weight above an eight inch bed of pea gravel placed below the valve. Wiring utilizes wire connectors and a four inch minimum clearance is maintained to the top of the valve box.
