A horizontal brace beam connects to the intersecting steel girder sized per plan. The connection utilizes a gusset plate attached with a five-sixteenth-inch fillet weld and bolted connections. Beams and girders are framed continuously through grid lines fifteen and X.
X 15 GIRDER PER PLAN BEAM PER PLAN HORZ BRACE BEAM PER PLAN 1/2" 1/2" 5/16 GIRDER PER PLAN 7 3.S-513
