A post or pylon is positioned alongside a pedestrian pathway with dimensional parameters for cane detection. The height restriction indicates the lower edge must be no higher than twenty-seven inches maximum above the finished floor to allow cane contact before a person hits the hazard. A clear width dimension is maintained for the pathway.
